R Series CrankcaseX

  • Max Operating Pressure 34.5 BAR / 500 PSl
  • Flow Area .364 SQ IN
  • Nozzle Thread 3/4″ FNPT
  • Receiver Thread
    OD 1-5/8″ 12 TPI
    ID 1-5/16” 12 TPI(-16ORB)
  • Latching Mechanism Ball Latching

R Series Couples are used for remote bulk-head mounting for common fluids. The receiver’s dual threads are designed to allow bulk-head mounting using the male thread and connection of a hose to the leak free female ORB thread. R series couplers DO NOT connect with Standard couplers.

SKU sV15sdddadf0Fd-1 Category Tag

Description

  • Max Operating Pressure 34.5 BAR / 500 PSl
  • Flow Area .364 SQ IN
  • Nozzle Thread 3/4″ FNPT
  • Receiver Thread
    OD 1-5/8″ 12 TPI
    ID 1-5/16” 12 TPI(-16ORB)
  • Latching Mechanism Ball Latching

Additional information

Options

N100p, R100c, R100Jc
